iQ500 60 cm dishwasher Fully integrated

SN658X10MM


varioSpeed Plus for up to 3 times faster dishwashing and drying; innovative technologies for intelligent usability and perfection in every detail.

Highlights

Efficient, durable and quiet: the iQdrive motor.

Lower energy consumption with identical performance, short programme times with optimum results and always nice and quiet whatever the programme – all that is not a problem for the iQdrive motor. And on top of all these advantages, it runs virtually free from wear.

Display all programme info on the floor: timeLight.

The innovative timeLight projects the remaining time in minutes, the programme status, and even any error messages alternately on your kitchen floor. Absolutely nothing will get by you anymore.

Not just for your cutlery, but also for your espresso cups: the varioDrawer.

The varioDrawer offers an additional loading level. Thanks to its special design it not only provides room for cutlery, but also for ladles, salad servers and even small items of crockery such as espresso cups. And as there is no longer a cutlery basket in the bottom basket, there is now space for a total of 14 standard place settings.

Loading lots of dishes is easy:

The basket is equipped with special devices at the top. If they are pressed, the height of the top basket can be easily adjusted in three stages. That makes loading and unloading simpler, particularly when dealing with large pots or plates.

Specialized in gentle cleaning: The Glass 40 °C cycle.

Fine glassware requires special care in cleaning. Siemens’ new Glass 40 °C cycle is specifically designed to meet this need. It first cleans glasses carefully but thoroughly at low temperatures. This is followed by a drying phase which has been specially extended for extra-gentle drying. The results are impressive: gleaming glassware you’ll be able to enjoy for a much longer time.

For particularly dry dishes: extraDry.

If you wish to wash a lot of plastic dishes, select the new Siemens extraDry programme. It uses higher temperatures for the drying process and extends the drying phase. Every plastic item will be dried optimally.

More flexibility during loading: the height-adjustable top basket.

Many Siemens dishwashers are equipped with height-adjustable top baskets for flexible loading of dishes of different heights. Whether you want to load tall glasses on top or large plates on the bottom, you can easily accommodate large dishware by adjusting the height of the top basket.

Optimum dishwashing results at the touch of a button: autoProgramme.

After the autoProgramme button has been pressed, aquaSensor checks how dirty the water is and controls when and how much clean water is added as well as the dishwashing temperature.

Gentle, safe, clean: the glassCare System.

The glassCare System – consisting of glass protection technology, a special gentle programme, and a heat exchanger – will wash your glassware with the greatest of care.

Additional information

Product details
  • Capacity: 14 place settings place settings
  • Energy Class: 5 Energy Stars
  • Energy consumption in programme Eco 50: 253 kwhper year, based on 280 standard cleaning cycles using cold water fill and the consumption of the low power modes. Actual energy consumption will depend on how the appliance is used.
  • Energy consumption in programme Eco 50: 0.904 kwh
  • Power consumption off-mode / left-on mode: NO_FEATURE / NO_FEATURE
  • Water consumption in programme Eco 50: 2576 litres per year, based on 280 standard cleaning cycles. Actual water consumption will depend on how the appliance is used.
  • Consumption in programme Eco 50: 2576 litres water per year / 253 kwh energy per year. Based on 280 standard cleaning cycles using cold water fill and the consumption of the low power modes.
  • Drying efficiency class NO_FEATURE on a scale from G (least efficient) to A (most efficient)
  • The information relates to the programme ​Eco 50. This programme is suitable to clean normally soiled tableware and is the most efficient programme in terms of combined energy and water consumption.
  • Programme time in programme Eco 50: 195 min
  • Duration of the left-on mode: NO_FEATURE
  • Noise level: 39 dB (re 1 pW)
  • Noise level (silence programme): not available(A) re 1 pW
  • Fully integrated
  • Energy consumption when connected to hot water in programme Eco 50: 0.7 kwh
  • 8 Programme: Auto 45-65 °C, Auto 35-45 °C, Intensiv 70 °C, Eco 50 °C, Glas 40 °C, 1h 65 °C, Schnell 45 °C, Vorspülen
  • 4 special options: Intensive Zone, VarioSpeedPlus, HygienePlus, Extra Trocknen
  • 6 cleaning temperatures
  • speedMatic hydraulic system
  • DosageAssist
  • BLDC motor for heat and drain pump
  • Aqua-Sensor, Load Sensor
  • Detergent Automation
  • Heat exchanger
  • Drying Assistent
  • Alternating spray technique
  • Regenerative electronics
  • Self-cleaning filter system with 3-fold corrugated filter
  • Stainless steel
  • black
  • Push button top controls
  • Time remaining indicator internal
  • Acoustic end of cycle indicator
  • rem. time proj. White
  • LED colour on indicators blue/white
  • Electronic delay timer: 1-24 hours
  • LED salt refill indicator
  • LED rinse aid refill indicator
  • yes
  • Silver XXL baskets
  • rackMatic height-adjustable top basket (3 stage)
  • 2 foldable plate racks in top basket
  • 4 foldable plate racks in bottom basket
  • 2 lever (long/short) 2
  • aquaStop with guarantee - Prevent Water Leakage
  • Servo lock for effortless door closing
  • Front-adjustable rear foot
  • Inclusive Steam protection plate
  • Dimensions of the product (HxWxD): 81.5 x 59.8 x 55 cm
Technical Information
General
Width of the product (mm) 598 mm
Height (mm) 815 mm
Installation typology Full-integrated
Number of place settings 14
Water consumption (l) 9.2 l
Total annual energy consumption 199.4 kWh
List of programmes Auto, Economy, Glass, Intensive, Pre-Rinse, Quick wash
Additional operational options Extra dry, HygienePlus, Intensive Zone, Machine Care, VarioSpeedPlus
Digital countdown indicator
Noise level (dB) 39
3rd Rack 3rd Rack 1.1
Interior light
Removable top
Length electrical supply cord (cm) 175 cm
Length outlet hose (cm) 190 cm
Connectivity
Home Connect
Construction type
Color / Material panel Black
Installation type Built-in
Door panel options Not possible
Drying system Heat exchanger
Height (mm) 815 mm
Hidden heating element
Installation typology Full-integrated
Removable top
Tub material Stainless steel
Water softener
Width of the product (mm) 598 mm
Size and weight
Height with worktop (mm) 815 mm
Number of Options 5
Adjustable plinth both horizontal and vertical
Net weight (kg) 47.9 kg
Programmes
List of programmes Auto, Economy, Glass, Intensive, Pre-Rinse, Quick wash
Name, programme 1 Auto
Name, programme 2 Auto
Name, programme 3 Intensive
Name, programme 4 Economy
Name, programme 5 Glass
Name, programme 6 Quick Wash
Programme duration, programme1 (min.) 90-160
Programme duration, programme2 (min.) 65-80
Programme duration, programme3 (min.) 125-135
Programme duration, programme4 (min.) 195
Programme duration, programme5 (min.) 85-90
Programme duration, programme6 (min.) 60
Reference programme Eco
Number of different wash temperatures 6
Temperature, programme 1 (°C) 45-65
Temperature, programme 2 (°C) 35-45
Temperature, programme 3 (°C) 70
Temperature, programme 4 (°C) 50
Temperature, programme 5 (°C) 40
Temperature, programme 6 (°C) 65
Safety
Glass protection techn.
Surge-back protect. installed
Water protection system Total system
Consumption values
Glass protection techn.
Total annual energy consumption 199.4 kWh
Energy consumption (kWh) 0.90 kWh
Energy consumption, programme1 (kWh) 0.95-1.6
Energy consumption, programme2 (kWh) 0.7-.85
Energy consumption, programme3 (kWh) 1.45-1.5
Energy consumption, programme4 (kWh) 0.904
Energy consumption, programme5 (kWh) 0.85-.9
Energy consumption, programme6 (kWh) 1.3
Water consumption, programme 1 (l) 7-18
Water consumption, programme 2 (l) 10-15
Water consumption, programme 3 (l) 12-15
Water consumption, programme 4 (l) 9.2
Water consumption, programme 5 (l) 11-14
Water consumption, programme 6 (l) 10
Water consumption (l) 9.2 l
Maximum temperature for water intake (°C) 60 °C
Connection
Connection Rating (W) 2,400 W
Length electrical supply cord (cm) 175 cm
Current (A) 10 A
Length inlet hose (cm) 140 cm
Length outlet hose (cm) 190 cm
Plug type GB plug
