Technical Overview
Installation type
Built-in
Type of appliance width
90 cm
Colour of appliance
Silver metallic
Sound power at max. speed (2010/30/EC)
63 dB
Maximum output air extraction
266 m³/h
Boost position air extraction
412 m³/h
Ventilation type
Convertible
Highlights
Special Features
iQdrive motor - The quiet, high-performance motor ensures efficient removal of odours and steam. for optimal visibility and ambience while cooking. Type of appliance width
90 cm
Color body
Silver metallic
Installation type
Built-in
Ventilation type
Convertible
Total power of the motors
70 W
Controls
LED, Low-lift pushbuttons
Number of speed settings
3-stages + intensive setting
Maximum output air extraction
266 m³/h
Boost position air extraction
412 m³/h
Sound power at max. speed (2010/30/EC)
63 dB
Sound power boost (2010/30/EC)
70 dB
Maximum output recirculating air
166 m³/h
Boost position output recirculating
178.0 m³/h
Sound power at max. speed (recirculation)
70 dB
Sound power boost (recirculation)
71 dB
Grease filter material
Washable aluminium
Energy efficiency rating
A
Total annual energy consumption
22.6 kWh/annum
Width of the appliance
898 mm
Minimum distance above an electric hob
430 mm
Minimum distance above a gas hob
650 mm
Diameter of air outlet
150 / 120 mm
Length electrical supply cord
175.0 cm
Appliance height exhaust air max
203 mm
Appliance height exhaust air min
203 mm
Appliance height recirculating max
203 mm
Appliance height recirculating min
203 mm
Maximum width for installation
526 mm
Minimum width for installation
526 mm
Depth for installation
290 mm
Control your hood with your Home Connect hob
No
Delay Shut off modes
10 min
Total power of the lamps
6 W
Colour temperature
Neutral (3.500 K)
Illumination type softlight
No
Color temperature control via smartphone with Home Connect
No
Power consumption standby/display off
0.2 W
