IQ700 Integrated Design Hood 60 cm Clear glass black printed, Matt blackLJ68BET60B
LJ68BET60B
Quiet Model
1 / 0
IQ700 Integrated Design Hood 60 cm Clear glass black printed, Matt blackLJ68BET60B
LJ68BET60B
Datasheet
Find a local Dealer
Find a local dealer in your vicinity
Quiet Model
This product is a Quiet Model
Operates at low decibel levels for minimal disruption without sacrificing power. Browse the range of appliances with the Quiet Model label.
IQ700 Integrated Design Hood 60 cm Clear glass black printed, Matt blackLJ68BET60B
LJ68BET60B
Datasheet
Find a local Dealer
Find a local dealer in your vicinity
Quiet Model
This product is a Quiet Model
Operates at low decibel levels for minimal disruption without sacrificing power. Browse the range of appliances with the Quiet Model label.
Technical Overview
Installation type
Built-in
Type of appliance width
60 cm
Control your hood with your Home Connect hob
Yes
Noise level
57 dB(A) re 1 pW
climateControl sensor
Yes
Ventilation type
Convertible
Maximum output air extraction
427 m³/h
Boost position air extraction
851 m³/h
Awards
Specifications
Type of appliance width
60 cm
Color body
Matt black
Installation type
Built-in
Ventilation type
Convertible
Total power of the motors
190 W
Controls
touch control,
Number of speed settings
3-stage + 2 intensive
Maximum output air extraction
427 m³/h
Boost position air extraction
851 m³/h
Sound power at max. speed (2010/30/EC)
57 dB
Sound power boost (2010/30/EC)
73 dB
Maximum output recirculating air
414 m³/h
Boost position output recirculating
656.0 m³/h
Sound power at max. speed (recirculation)
66 dB
Sound power boost (recirculation)
76 dB
Grease filter material
Washable stainless steel
Energy efficiency rating
A+
Total annual energy consumption
35.3 kWh/annum
Included user manuals
[AR, EN]
Nominal power
220-240 V
Height of the appliance
60 mm
Width of the appliance
598 mm
Dimensions
298 mm
Dimensions of the packed product (HxWxD)
500x580x720 mm
Height of the chimney
GENERAL.N_A mm
Minimum distance above an electric hob
430 mm
Minimum distance above a gas hob
650 mm
Diameter of air outlet
150 mm
No-return airflow flap
No
Length electrical supply cord
130 cm
Weight
9.1 kg
Handle bar
Not applicable
Appliance height exhaust air max
340 mm
Appliance height exhaust air min
340 mm
Appliance height recirculating max
340 mm
Appliance height recirculating min
340 mm
Maximum width for installation
560 mm
Minimum width for installation
560 mm
Depth for installation
300 mm
1 / 0
climateControl sensor
Yes
iQdrive
Yes
Silence
Yes
Clean filter reminders
Yes
Boost position
Yes
Delay Shut off modes
Yes
Remote control
No
Type of lamps used
LED
Number of lights
2
Total power of the lamps
GENERAL.N_A W
Total luminance
437 lux
Colour temperature
Neutral (3.500 K)
Illumination type softlight
Yes
Color temperature control via smartphone with Home Connect
Yes
emotionLight Pro
No
Home ConnectFootnote 1: Some of the features displayed can be accessed only if the device is connected to a Home Connect Account and a SingleKey ID account via the Internet. Home Connect is a service of Home Connect GmbH. For more information on Home Connect, visit www.home-connect.com.
Yes
Home Connect Features
iService Remote, Remote Monitoring and Control
Control your hood with your Home Connect hob
Yes
Smart Hood Automatic
No
