Technical Overview
Product name/family
Cooking zone ceramic
Dimensions
227 x 792 x 512 mm
Type of frame
Flush-mounted Studioline
Highlights
Special Features
flexInduction – Smart cooking zone that adapts to your cookware. Dual light slider – Just touch and slide to control your hob. climateControl Sensor – Monitors steam and smells, adjusts the power level automatically. integrate your hob into your intelligent kitchen. the supplementary available sensor prevents overboiling thanks to precise temperature control.
Type of appliance width
80 cm
Dimensions of the heating elements
1 x (40,0 x 24,0 cm), 1 x (40,0 x 24,0 cm)
Power of the heating elements (maximum values shown, depending on gas type)
4 x 2.2 (3.7) kW
Number of radiant plates
0
Number of induction plates
4
Controls
illuminated, dual lightSlider, front
Ventilation type
Convertible
Maximum output air extraction
500 m³/h
Boost position air extraction
622 m³/h
Maximum output recirculating air
499 m³/h
Boost position output recirculating
595.0 m³/h
Sound power at max. speed (2010/30/EC)
69 dB
Sound power boost (2010/30/EC)
74 dB
Noise level
69 dB(A) re 1 pW
Energy consumption of hob
185.0 Wh/kg
Included accessories
1 x Slider for unducted recirculation, 1 x Clean Air Plus odor filter
Dimensions
227 x 792 x 512 mm
Minimum height for installation
500 mm
Minimum width for installation
780 mm
Depth for installation
227 mm
Appliance height above the worktop
0.0 mm
Nominal power
220-240/380-415 V
Length electrical supply cord
110.0 cm
Plug type
no plug (electrical connection by electrician)
Included user manuals
[DE, FR]
Type of control
Dual lightSlider
hotplate control settings
17 power levels
Cooking zone flexibility
2 flex induction cooking zones
Infrared cooking sensor
No
cookingSensor Plus ready (sensor available as additional purchase)
Yes
Delay Shut off modes
30R_12E min
Power consumption standby/display off
0.5 W
Power consumption standby/network: Please check the user manual for how to switch off the WiFi module.
2.0 W
Time auto-standby/displ. off
20.0 min
Time auto-standby/network
20.0 min
Residual heat indicator
Separate
Safety device
Key Lock, childproof lock, Power management function, pan recognition, Safety time-switch-off
