Technical Overview
Installation type
Wall-mounted
Type of appliance width
90 cm
Sound power at max. speed (2010/30/EC)
57 dB
Maximum output air extraction
394 m³/h
Boost position air extraction
717 m³/h
Ventilation type
Convertible
Highlights
Special Features
ensures efficient odour and steam removal. Perfect cooperation Adapt your extractor hood to your style. Access and control your hood, no matter where you are For optimal visibility and ambience when cooking. Type of appliance width
90 cm
Installation type
Wall-mounted
Ventilation type
Convertible
Total power of the motors
140 W
Controls
2x7-Segment, LED, touch control
Number of speed settings
3-stage + 2 intensive
Maximum output air extraction
394 m³/h
Boost position air extraction
717 m³/h
Sound power at max. speed (2010/30/EC)
57 dB
Sound power boost (2010/30/EC)
70 dB
Maximum output recirculating air
311 m³/h
Boost position output recirculating
578.0 m³/h
Sound power at max. speed (recirculation)
60 dB
Sound power boost (recirculation)
74 dB
Grease filter material
Washable aluminium
Energy efficiency rating
B
Total annual energy consumption
40.0 kWh/annum
Height of the appliance
430 mm
Width of the appliance
890 mm
Minimum distance above an electric hob
450 mm
Minimum distance above a gas hob
600 mm
Diameter of air outlet
120 / 150 mm
Length electrical supply cord
130.0 cm
Appliance height exhaust air max
1239 mm
Appliance height exhaust air min
969 mm
Appliance height recirculating max
1299 mm
Appliance height recirculating min
1029 mm
Control your hood with your Home Connect hob
Yes
Delay Shut off modes
10 min
Colour temperature
Neutral (3.500 K)
Illumination type softlight
Yes
Color temperature control via smartphone with Home Connect
No
Home Connect Features
Remote Monitoring and Control
Power consumption standby/display off
0.5 W
